Lab 1: FPGA and MCU Setup and Testing

Explore the microcontroller unit (MCU) and field-programmable gate array (FPGA) development boards used in this course.

Introduction

In this lab I assembled the E155 development board, verified power rails, and brought up both the UPduino v3.1 FPGA (iCE40-UP5K) and the Nucleo-L432KC MCU. I then wrote SystemVerilog to (1) drive three LEDs per the given truth tables and (2) decode a 4-bit input from the on-board DIP switches (SW6) to a common-anode 7-segment display. The switches provide s[3:0] directly into the FPGA; the decoder drives seg[6:0] (active-low) through 1k ohm resistors to the display so that the selected hex digit lights correctly. Designs were simulated in QuestaSim, synthesized in Lattice Radiant, and programmed to the UP5K;

Design & Testing Methodology

Architecture

• Internal 48 MHz HSOSC feeds a power-on reset counter and a parameterized divider that creates a ~2.4 Hz tick for led[2].
• led_logic implements the required LED truth tables and optional active-low polarity.
• SevenSeg is a combinational hex→segments decoder with active-low outputs (for a common-anode display).

Figure 1: Block diagram of the top-level (sbf_lab1).

Unit tests (simulation)

Self-checking testbenches read .tv vectors: - tb_SevenSeg_tv verifies the 0x0–0xF map. - tb_led_logic_tv checks both active-high and active-low instances. - tb_lab1_sbf_tv checks seg and led[1:0] at top level (blink bit ignored).

On the single “error”: one vector intentionally contains unknowns (xxxxxxx) to represent a “don’t-care” state during initialization. The testbench expects xxxxxxx, while real hardware (with pull-ups and reset) resolves to 1111111 (all segments off). Functionally correct; the failure is in the expected vector, not the DUT.

Hardware bring-up

• Verified +5 V and +3.3 V LDO outputs on VIN power before inserting modules.
• Wired one side of the dual 7-segment (common-anode) with series resistors on each segment; anode to 3.3 V.
• Used ~1 kΩ series resistors → ≈3.3 mA/segment (ignoring LED (V_f)), comfortably within limits: [ I = 3.3  ]

Figure 2: Hand-drawn schematic and current note (common-anode with ~1 kΩ resistors).

Technical Documentation

• Code directory: https://github.com/s4anti4go/E155/tree/main/FPGA/RadiantProject/Lab%201
  • FPGA design: `sbf_lab1 (top).
  • Testbenches: tb_all.sv.
• Tools: Radiant (synthesis, constraints, Netlist Analyzer), QuestaSim Lattice Edition (simulation), SEGGER Embedded Studio (MCU).

LED behavior specification

S1	S0	led[0]
0	0	OFF
0	1	ON
1	0	ON
1	1	OFF

S3	S2	led[1]
0	0	OFF
0	1	OFF
1	0	OFF
1	1	ON

led[2] blinks at ~2.4 Hz from the divider: \[ \mathrm{TOGGLE\_COUNT} = \frac{48\,\mathrm{MHz}}{2 \cdot 2.4\,\mathrm{Hz}} - 1 = 10{,}000{,}000 - 1 \]

Seven-segment notes

• Common-anode display → active-low segment lines (0 turns a segment on).
• Naming: seg[0]=A … seg[6]=G.
• To turn on correct segments:

Results & Discussion

Seven-segment unit tests

Figure 3: SevenSeg waves across 0x0–0xF.

Figure 4: SevenSeg transcript (1 expected X-case mismatch at vec 0).

LED logic unit tests

Figure 5: LED logic waves (active-high and active-low instances).

Figure 6: LED logic transcript (all pass).

Top-level simulation

Figure 7: Top-level (sbf_lab1) QuestaSim waves sweeping s=0..F.

Figure 8: Top-level transcript (1 error corresponds to X-expectation init vector).

Interpretation.
- led_logic passes all vectors for both polarities.
- SevenSeg and top-level each show one flagged vector where the testbench expects unknowns; hardware resolves to all off (1111111). Functionality is correct; the discrepancy is only in the expected file’s init case.
- Divider math and POR behavior match intent; led[2] toggles at the expected rate (simulation time scaled).

Conclusion

I assembled and powered the E155 dev board, verified MCU↔︎FPGA connectivity, and implemented the required FPGA logic: LED truth tables, a ~2.4 Hz blink, and a combinational 7-segment decoder for a common-anode display. Simulation, synthesis, and on-board testing confirm correct behavior. The lone “failure” in automated tests is a deliberate X-expectation vector that resolves to “all off” in hardware.

Time spent: 20 hours.

All Code https://github.com/s4anti4go/E155/tree/main/FPGA/RadiantProject/Lab%201

AI Implementation

Prompt

Write SystemVerilog HDL to leverage the internal high speed oscillator in the Lattice UP5K FPGA and blink an LED at 2 Hz. Take full advantage of SystemVerilog syntax, for example, using logic instead of wire and reg.

What the LLM produced (Gemini)

Good ideas it used: - Parameterized divider (CLK_FREQ, BLINK_FREQ) with $clog2 sizing - Modern SV constructs (logic, always_ff) - Clear split: top module that wraps an oscillator primitive + a blinker child

Top-level snippet returned (abridged): module led_blink_top (output logic o_led); logic clk_48mhz; SB_HFOSC u_hfosc ( .CLKHFPU(1’b1), .CLKHFEN(1’b1), .CLKHF(clk_48mhz) ); defparam u_hfosc.CLKHF_DIV = “0b00”; // 48 MHz led_blinker u_led_blinker (.clk(clk_48mhz), .led(o_led)); endmodule

Synthesis outcome

Radiant failed at the oscillator instantiation with: VERI-1063: instantiating unknown module SB_HFOSC Root cause: Radiant’s iCE40 UltraPlus technology library expects the HSOSC primitive, not SB_HFOSC (the SB_* form is common in iCEcube2 examples).

Fix applied (works in Radiant): // iCE40UP internal HF oscillator HSOSC #(.CLKHF_DIV(2’b00)) // 00 = 48 MHz hf_osc (.CLKHFPU(1’b1), .CLKHFEN(1’b1), .CLKHF(clk));

I also replaced the LLM’s initial-based register inits with a tiny synchronous power-on reset (POR) counter so hardware powers up in a known state.

Quality rating (and why)

• Rating: B

• Strengths: idiomatic SV, readable, correct divide-by-N math, parameterized for reuse

• Weak spots: vendor primitive mismatch (SB_HFOSC vs HSOSC), defparam string style ("0b00"), reliance on initial for synthesis reset

What I learned / new constructs

• $clog2 is handy for auto-sizing counters and synthesizes cleanly on UP5K.
• Parameterizing the blink frequency made switching between 2 Hz (prompt) and 2.4 Hz (lab) a one-line change.

Errors & warnings encountered

• Radiant: VERI-1063 instantiating unknown module SB_HFOSC → resolved by switching to HSOSC #(.CLKHF_DIV(2'b00)) and wiring CLKHFPU/CLKHFEN/CLKHF.

Tips for using LLMs for HDL (next-time playbook)

1. Specify tool, family, and exact primitive in the prompt: target Lattice Radiant for iCE40 UltraPlus (UP5K) and instantiate HSOSC (ports CLKHFPU, CLKHFEN, CLKHF; param CLKHF_DIV).
2. Ask for a synthesizable reset: avoid initial; include a synchronous reset or a small POR counter.
3. Request a sim-friendly testbench: faster divider + self-check to validate logic quickly.
4. Ask for Radiant-specific guidance: prefer Device Constraint Editor notes over generic .lpf.
5. Iterate with exact error text: paste Radiant/Questa messages back to the LLM for precise fixes.
